Bushranger Spartan RTHD 61in Zero Turn Mower
Bushranger Spartan RTHD 61in Zero Turn Mower
Regular price
$23,999.00
Regular price
Sale price
$23,999.00
Inc GST.
Not Stocked – Order In
Usually ready: 2–14 business days
Quantity
Couldn't load pickup availability
Bushranger Spartan RTHD 61" Zero Turn Mower
The Bushranger Spartan RTHD 61" is a heavy-duty commercial zero-turn mower built for large properties and demanding mowing jobs. Its 27 HP Kawasaki FX850V V-twin engine, Parker HTJ 12 cc wheel motors and wide 61" fabricated steel deck combine power, control and cutting coverage.
With a 35.9-litre fuel capacity and ground speeds up to 17.7 km/h, the RTHD 61" is ready for long working days. Settle into the TCB-3 TecsPak 360 floating seat, keep your controls within easy reach and adjust cutting height on the go with the shock-assisted foot lift. GT-Trac technology, a low centre of gravity and turf radial tyres support traction and control, while onboard storage keeps the essentials close.
Features
- Kawasaki FX850V V-twin engine producing 27 HP (20.1 kW).
- Parker HTJ 12 cc wheel motors.
- Infinitely variable ground speed up to 17.7 km/h.
- 35.9-litre fuel capacity.
- 61" side-discharge deck with anti-scalp wheels.
- 6" deep, reinforced 7-gauge fabricated steel XTF deck.
- On-the-go deck height dial with shock-assisted foot lift.
- Cast aluminium spindles with four sealed bearings per spindle.
- Long-life deck belts with large idler pulleys and vibration control deck system.
- Heavy-duty steel frame and GT-Trac system for traction, balance and incline control.
- Foot-operated parking brake.
- Push-start keypad and LCD panel with engine hour meter, deck hour meter and tachometer.
- 12V outlet, large cup holder, phone holder and deep storage tray.
- TCB-3 TecsPak Elastomer seat with 360 Floating System.
- 24" turf radial drive tyres and 13" radial front caster tyres.
- Open deck design for improved grass clearance.
- Tow hitch included.
Specifications
| Specification | Details |
|---|---|
| Domestic Warranty | 3 years / 500 hours, whichever comes first |
| Commercial Warranty | 2 years / unlimited hours |
| Hire / Rental Warranty | No hire / rental warranty |
| Dry Weight | 516.1 kg (1,137.8 lbs) |
| Height | 75" (1,905 mm) with ROPS up; 54" (1,372 mm) with folding ROPS down |
| Width | 62.5" (1,587.5 mm) with discharge chute raised |
| Length | 84" (2,133.6 mm) |
| Forward Ground Speed | Infinitely variable, 0–17.7 km/h |
| Brakes | Foot-operated parking brake |
| Caster Tyres | 13", radial |
| Drive Tyres | 24" turf radials |
| Seat | TCB-3 TecsPak Elastomer Dampeners with 360 Floating System |
| Frame Construction | 1.5" × 3" (38.1 × 76.2 mm) powder-coated, fusion-bonded solid steel bridge frame |
| Front Caster Bearings | Commercial-duty, greaseable roller bearings on each wheel |
| Hour Meter | Standard |
| Controls | Twin-lever steering, push-start keypad, hand-operated choke and throttle |
| Display | LCD panel with engine and deck hour meters and tachometer |
| Cup Holder | Large cup holder moulded into the right-side mudguard, accommodating nearly any cup size |
| Deck System | 61" (1,550 mm) side-discharge deck with three blades, four-point suspension and deck-mounted anti-scalp wheel(s) for improved flotation on rolling and uneven terrain |
| Deck Lift | Foot-operated with shock assist |
| Deck Construction | 6" deep, reinforced 7-gauge fabricated steel with 7-gauge spindle mounts and 9/16" impact bar |
| Blade Tip Speed | 18,749 ft/min / 5,714.69 m/min |
| Blade Drive | V-belt drive to spindles with electric clutch and spring-tension idler pulleys for extended belt life |
| Spindles | Cast aluminium with four sealed bearings per spindle |
| Drive System | V-belt drive from engine crankshaft |
| Discharge Chute | High-density, rubberised |
| Open Deck | No restricting bar on the discharge side, helping grass clear the deck and discharge chute |
| Steering | Twin-lever steering with independent control of each drive wheel. Hand-operated controls manage speed, forward, reverse, braking and turning |
| Blades | Three heavy-duty blades |
| Engine | Kawasaki FX850V |
| Engine Type | Air-cooled, 90-degree V-twin, normally aspirated petrol engine |
| Horsepower | 27 HP (20.1 kW) at 3,600 rpm, tested to SAE J1995 standards |
| Power Output | 12-volt, subject to engine manufacturer specifications |
| Cooling | Air-cooled with flywheel fan |
| Fuel | Unleaded petrol with a maximum of 10% ethanol, subject to engine manufacturer specifications |
| Fuel Filter | Replaceable, automotive-type |
| Oil Filter | Spin-on engine oil filter |
| Total Oil Capacity | 2.5 US quarts (2.4 litres), including filter |
| Air Filter | Heavy-duty, canister-style air cleaner for extended service intervals in dirty conditions and improved performance |
| Fuel Capacity | 35.9 litres |
| Governor | Mechanical |
| Hydrostatic Drive System | Parker HTJ 12 cc wheel motors |
| Cutting Width | 61" (1,550 mm) side discharge |
| Cutting Height | 1.5"–5.5" (38.1–139.7 mm), 15 positions and travel lock |
| Cutting Height Adjustment | On-the-go deck height dial with shock-assisted foot-operated deck lift |
